| Brand Name: | WANBANDA,OEM |
| Model Number: | 3500 Customerized Clearcoat |
| MOQ: | 18L |
| Payment Terms: | TT, LC |
| Supply Ability: | 2000 Ton/Tons Per Month |
Practical Car Clear Coat Varnish Moistureproof Mirror Effect
HS 3500 Customerized Clearcoat
1, Product features: This product is a Mid-range varnish, with excellent leveling and fresh reflection, so that the paint surface to achieve the mirror-like effect, and after drying the paint film gloss is very stable, excellent hardness.
2, Application: Especially suitable for high quality car factory or 4S shop or high-end car refurbishment.
3, Substrate: Suitable for coating the surface of the workpiece sprayed with one component (1K) base paint
4, Mixing ratio (volume ratio) : 100:50:10-15
5, Viscosity and time limit: when used, it should be mixed evenly, spraying viscosity is 15 ~ 17 seconds (coating -4 cups, 25ºC), use time limit is 4h/25ºC.
6, Spraying requirements: choose the diameter of 1.3 ~ 1.7mm spray gun, the working pressure is 3 ~ 5bar, spray 2-3 channels, film thickness is 40 ~ 60um, each channel is separated by 10 ~ 20 minutes, after spraying, stand for 20 ~ 30 minutes to bake.
7, Drying method and time: room temperature 25ºC/8 hours, bake 60ºC-70ºC/45-60 minutes.
8, Note: with different construction temperature and environment can choose standard drying, fast drying, slow drying series of hardener and diluent, in order to ensure the spraying effect, varnish and hardener must be fully stirred evenly. Please use a series of products, the effect is better after spraying.
| Characteristic: Double pack acrylic extra fast drying clear coat, easy application, good gloss, suitable for metal, solid basecoat and spot repair Substrates: 1K Plain |
|||||
| Surface Cleaning: | Clean the dust and particles with tack cloth | ||||
| Mixing Ratio | |||||
| Clear Coat | Hardener | ||||
| 2 | 1 | ||||
| <18°C | |||||
| 18-30°C | |||||
| >30°C | |||||
| Pot-Life at 25°C | |||||
| The mixture should be used up within 1 hour | |||||
| Spray Gun Set-up | |||||
| Gravity Feed | 1.2-1.5mm 3-5kg/cm2 |
Suction Feed | 1.4-1.7mm 3-5kg/cm2 |
||
| Conventional | 3-4 bar | RP | 2.0-2.5 bar | ||
| HVLP | 2.0 bar | ||||
| Coats & Thickness | |||||
| 2-3 coats, tatal 50-70 um | |||||
| Flash-off Time | |||||
| At 20°C, 5-10 minutes between coats | |||||
| Air-drying Time | |||||
| Allow 15-20 minutes air drying time before force drying | |||||
| Drying Time | |||||
| Temperature | Dust Free | Dry to Handle | Dry to Polish | ||
| 20°C | 30-40 minutes | 120 minutes | 6 days | ||
| 15°C | 20-30 minutes | 60 minutes | 6 days | ||
| 25°C | 15-20 minutes | 40 minutes | 6 days | ||
| 60°C | 5 minutes | 10 minutes | 80 minutes | ||
